MSI A520M-A Pro AM4 AMD Micro-ATX Motherboard

MSI A520M-A Pro AM4 AMD Micro-ATX Motherboard

Stock: In Stock
Model: MSI A520M-A Pro

Based on 0 reviews. - Write a review

Payment Option

8,100৳

Cash Discount Price

Online / Cash Payment

1,445৳/ month

Regular Price: 8,667৳

0% EMI for up to 6 Months***

Buy Now

Buy Now Add to Compare

Add to Wish List Add to Compare

Key Features

Model: MSI A520M-A Pro
AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
PCB with 2OZ Thickened Copper
Supports up to 4600(OC) MHz RAM
Core Boost, Turbo M.2 & Audio Boost

View more info

Specification

Basic Informations
Chipset	Chipset
Form Factor	Micro-ATX Form Factor 9.3 in. x 7.9 in. (23.6 cm x 20 cm)
Supported CPU	AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Connector & Ports
Audio	Realtek ALC892 Codec 7.1-Channel High Definition Audio
DVI-D (s)	1x DVI-D port, maximum resolution of 1920x1200@60Hz
HDMI	1x HDMI 2.1 port, maximum resolution of 4096x2160 @60Hz
Internal I/O Ports	1x 24-pin ATX main power connector 1x 4-pin ATX 12V power connector 4x SATA 6Gb/s connectors 1x M.2 slots (M-Key) 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x Clear CMOS jumper
LAN Port (s)	1x Realtek RTL8111H Gigabit LAN controller
Supported Storage	AMD A520 Chipset 4x SATA 6Gb/s ports 1x M.2 slot (Key M) (from AMD Processor) Supports PCIe 3.0 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices
TPM (Trusted Platform Module )	1xTPM module connector
USB (s)	AMD A520 Chipset 2x USB 3.2 Gen 1 5Gbps ports are available through the internal USB 3.2 Gen 1 5Gbps connector 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) AMD Processor 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
Expansion Slots
M.2 Socket	1x M.2 slot (Key M) (from AMD Processor) Supports PCIe 3.0 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices
PCI	1x PCIe 3.0 x1 slot 1x PCIe x16 slot
Memory
Maximum Memory	64GB
Slots	2x DDR4 memory slots
Supported Memory	Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE 1DPC 1R max speed 4600 MHz 1DPC 2R max speed 3866 MHz Supports non-ECC UDIMM memory Supports ECC UDIMM memory (non-ECC mode) Supports un-buffered memory
Type	Dual-channel memory architecture
Graphics
Graphics	1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
Max Shared Memory	16GB
Others
Special Features	RAID: Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices Warranty Information
Warranty
Manufacturing Warranty	03 Years Warranty

Description

MSI A520M-A Pro Motherboard

The MSI A520M-A Pro is a reliable AM4 Micro-ATX motherboard designed to deliver stable performance for everyday computing, office work, gaming, and entry-level system builds. Built with durability and efficiency in mind, it provides strong compatibility with AMD Ryzen processors while maintaining smooth and consistent system operation.

This motherboard features optimized power delivery and a well-designed PCB layout that enhances stability and heat management. Its enhanced copper layer design improves conductivity and thermal performance, helping maintain reliability during extended usage. The board also supports modern storage standards, allowing users to connect high-speed SSDs for faster data access and improved system responsiveness.

Smart Fan & Thermal Control

With advanced fan management features, users can monitor and control system temperatures through an intuitive interface. It allows customization of fan speed based on temperature conditions, ensuring balanced cooling performance and quieter operation. Users can set multiple temperature targets for better automatic fan adjustment.

Memory & Performance Optimization

The MSI A520M-A Pro supports A-XMP memory profiles, enabling users to easily unlock higher memory speeds and improved system performance with a simple setting. Compared to earlier motherboard generations, it provides better memory optimization and improved efficiency.

The motherboard also includes Core Boost technology, which ensures stable and efficient power delivery to supported processors. This feature improves CPU performance and provides better conditions for multitasking and basic overclocking support.

Storage & Connectivity Support

Designed to support modern storage devices, this motherboard allows connection to high-speed SSDs and storage drives for faster boot times and application loading. Its durable construction and optimized layout make it suitable for long-term use in budget-friendly and performance-oriented builds.

Buy MSI A520M-A Pro from PreKite

In Bangladesh, you can purchase the original MSI A520M-A Pro Motherboard from PreKite. We offer authentic products at competitive prices with reliable service for your PC build or upgrade.

Order online or visit your nearest PreKite store to get the best deal. This motherboard comes with a warranty as provided by the manufacturer.
