MSI PRO X870E-P WIFI AM5 ATX Motherboard

MSI PRO X870E-P WIFI AM5 ATX Motherboard

Stock: In Stock
Brand: Msi
Model: PRO X870E-P WIFI

Based on 0 reviews. - Write a review

Payment Option

36,800৳

Cash Discount Price

Online / Cash Payment

6,563৳/ month

Regular Price: 39,376৳

0% EMI for up to 6 Months***

Buy Now

Buy Now Add to Compare

Add to Wish List Add to Compare

Key Features

Model: PRO X870E-P WIFI
Supported CPU: AMD Ryzen 9000/8000/7000 Series for Socket AM5
Supported RAM: 4x DDR5 UDIMM, Up to 8200 (OC) Mhz
Graphics Output: 1x HDMI, 1x Type-C DisplayPort
Features: 3x M.2 Slot, Realtek 8126VB 5G LAN, Wi-Fi 7, Bluetooth 5.4

View more info

Specification

Basic Informations
Audio	Realtek ALC897 7.1-Channel High Definition Audio
BIOS	Flash BIOS Button
Chipset	AMD X870E
Form Factor	ATX 243.84mmx304.8mm
Supported CPU	Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Connector & Ports
Display Port (s)	1x Type-C DisplayPort
HDMI	1x HDMI
Internal I/O Ports	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 6x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 6x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports
LAN Port (s)	Realtek 8126VB 5G LAN
RAID	Supports RAID 0 , RAID 1 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices *RAID 5 configuration is only supported by Ryzen 9000 series processors.
Supported Storage	3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices 4x SATA 6G M2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors) *Please refer to the manual for M.2 SSD heatsink restrictions.
TPM (Trusted Platform Module )	1x TPM pin header(Support TPM 2.0)
USB (s)	4x USB 2.0 (Rear) 6x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 2x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Front) 1x USB 20Gbps Type C (Rear) 1x USB 40Gbps Type C (Rear)
Wireless Communication module	Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM * 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
Expansion Slots
M.2 Socket	3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4, supports 2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4, supports 22110/2280 devices
PCI	3x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E1 slot Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors) Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors) Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processors)
Memory
Maximum Memory	256GB
Slots	4x UDIMM
Supported Memory	Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8200+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 6000+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only * CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility. • The DIMM slots on this motherboard have double-sided latches.
Type	DDR5
Graphics
Graphics	1x HDMI Support HDMITM 2.1, maximum resolution of 4K 60Hz 1x Type-C DisplayPort USB4 port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 60Hz *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Others
Special Features	4x EZ Debug LED 1x EZ Memory Detection LED
Warranty
Manufacturing Warranty	3 Years

Description

MSI PRO X870E-P WIFI AM5 ATX Motherboard

The MSI PRO X870E-P WIFI AM5 ATX Motherboard is a powerful and future-ready platform designed for high-performance gaming, content creation, and professional workloads. Built to support AMD Ryzen 9000, 8000, and 7000 Series desktop processors on the AM5 socket, this motherboard delivers advanced performance with strong expansion potential and modern connectivity.

High-Capacity DDR5 Memory Support

Equipped with four DDR5 UDIMM slots, the motherboard supports up to 256GB of memory with speeds ranging from 4800 MT/s to 8200+ MT/s (OC). It supports AMD EXPO, JEDEC standards, dual-channel architecture, non-ECC unbuffered memory, and clock driver bypass mode, providing excellent compatibility and overclocking flexibility for demanding applications.

Integrated Graphics & Display Options

For users utilizing processors with integrated graphics, the board includes HDMI 2.1 and USB4 Type-C with DisplayPort 1.4 output, both capable of delivering 4K resolution at 60Hz. These options ensure high-quality visual output for productivity and multimedia use.

Expansion & PCIe 5.0 Support

The motherboard features multiple PCIe slots, including a primary PCIe 5.0 x16 slot (PCI_E1) supporting Ryzen 9000 and 7000 processors for next-generation graphics cards. This ensures maximum bandwidth and compatibility with high-end GPUs and expansion devices.

Advanced Storage & RAID Support

Storage flexibility includes:

Three M.2 slots with PCIe 5.0 and PCIe 4.0 support

Four SATA 6Gb/s ports

The M.2_1 slot supports PCIe 5.0 x4 for Ryzen 9000 and 7000 CPUs. RAID support includes RAID 0, 1, and 10 for SATA, and RAID 0, 1, and 5 for NVMe (on Ryzen 9000 CPUs), allowing users to optimize storage for speed or data protection.

Next-Generation Networking

This motherboard delivers ultra-fast connectivity with:

Wi-Fi 7 for advanced wireless performance

Bluetooth 5.4 for seamless device pairing

Realtek 8126VB 5G LAN for high-speed wired networking

These features ensure stable and fast internet connectivity for gaming, streaming, and professional workloads.

Extensive USB Connectivity

It offers a wide range of USB options, including:

USB 2.0 ports

5Gbps, 10Gbps, and 20Gbps USB ports

USB4 40Gbps Type-C port for ultra-fast data transfer and device connectivity

This extensive I/O support makes it ideal for modern peripherals, external storage, and high-speed accessories.

Built for Stability & Easy Management

The motherboard includes internal headers for:

CPU and system fans

RGB and ARGB lighting

TPM 2.0

Tuning controller connector

It also features EZ Debug and Memory Detection LEDs for easy troubleshooting and system monitoring.

With a standard ATX size of 243.84mm x 304.8mm, Windows 11 64-bit compatibility, strong power delivery, and cutting-edge connectivity, the MSI PRO X870E-P WIFI is a premium choice for users building a high-end gaming or workstation system.

Buy MSI PRO X870E-P WIFI AM5 ATX Motherboard from PreKite

In Bangladesh, you can purchase the original MSI PRO X870E-P WIFI AM5 ATX Motherboard from PreKite. We offer the latest MSI motherboards for desktop PC builds at competitive prices. Order online or visit your nearest PreKite store to get it at the best available price.

The MSI PRO X870E-P WIFI AM5 ATX Motherboard comes with a 3-year warranty.
